YT-11 High Longitude Remote Control Digital Angle Positioning Instrument
The YT-11 is a high-precision remote-controlled angle-finding and positioning system designed specifically for military reconnaissance. Its key advantage lies in significantly reducing the risk of casualties among frontline personnel—reconnaissance personnel can operate the equipment separately, achieving remote video and data control via low-latency RTSP transmission. It possesses high-precision positioning capabilities (orientation accuracy ≤0.02°, target positioning error ≤6 meters at 12 km), supporting reliable positioning in multiple coordinate systems and GPS-denied environments. Employing a modular design, it can flexibly adapt to payloads such as laser rangefinders and infrared sensors, and supports customization, balancing ease of operation with mission adaptability, making it suitable for the precision reconnaissance needs of joint operations and complex environments.
● Reduces losses of frontline reconnaissance personnel.
Supports low-latency RTSP transmission of raw video signals, and synchronous two-way transmission of distance, position, angle, and control information. Reconnaissance personnel and equipment can be separated and integrated into joint operations systems.
● High-precision absolute value encoding for magnetic north and non-magnetic north orientation
, accuracy ≤0.02°, supports manual/reference point/map orientation.
● Multiple self-positioning modes (including GPS denial)
. Supports built-in/external GNSS positioning, and manual/reference point/map positioning.
● Ultra-high precision target positioning accuracy
≤6 meters @ 12000 meters (with IR101Z/LRF25K laser rangefinders, etc.).
● Supports multi-coordinate system transformation (SK42/WGS84, Gauss-Kruger/UTM/MGRS),
including ellipsoidal coordinate system SK42/WGS84 and custom GIS parameters, and rectangular coordinate system Gauss-Kruger/UTM/MGRS.
● Manual/Electric/Remote Control Switching:
Manual rotation of the positioning device maintains high-precision target positioning; electric control offers small/large step speed adjustment; RTSP remote control is also available. All three modes can be used simultaneously.
● User-Friendly Operation: Quick and easy to learn,
Android-based smartphone setup; positioning data can be overlaid on maps, lowering the barrier to entry.
● Modular Design
for Multiple Task Scenarios: Suitable for various payloads (laser rangefinders, infrared, CMOS visible light, direct-view optics, laser illuminators, etc.) depending on the task scenario.
● Customization Supported:
Customized payloads can be customized for specific task scenarios.
Supports low-latency RTSP transmission of raw video signals, and synchronous two-way transmission of distance, position, angle, and control information. Reconnaissance personnel and equipment can be separated and integrated into joint operations systems.
● High-precision absolute value encoding for magnetic north and non-magnetic north orientation
, accuracy ≤0.02°, supports manual/reference point/map orientation.
● Multiple self-positioning modes (including GPS denial)
. Supports built-in/external GNSS positioning, and manual/reference point/map positioning.
● Ultra-high precision target positioning accuracy
≤6 meters @ 12000 meters (with IR101Z/LRF25K laser rangefinders, etc.).
● Supports multi-coordinate system transformation (SK42/WGS84, Gauss-Kruger/UTM/MGRS),
including ellipsoidal coordinate system SK42/WGS84 and custom GIS parameters, and rectangular coordinate system Gauss-Kruger/UTM/MGRS.
● Manual/Electric/Remote Control Switching:
Manual rotation of the positioning device maintains high-precision target positioning; electric control offers small/large step speed adjustment; RTSP remote control is also available. All three modes can be used simultaneously.
● User-Friendly Operation: Quick and easy to learn,
Android-based smartphone setup; positioning data can be overlaid on maps, lowering the barrier to entry.
● Modular Design
for Multiple Task Scenarios: Suitable for various payloads (laser rangefinders, infrared, CMOS visible light, direct-view optics, laser illuminators, etc.) depending on the task scenario.
● Customization Supported:
Customized payloads can be customized for specific task scenarios.
|
Product Model |
YT-11 |
|
Performance parameters |
|
|
load |
≥4Kg (center of gravity not higher than 5cm above the mounting surface) |
|
Maximum power consumption |
20W |
|
Normal power consumption |
8.4W |
|
Rotation angle range |
Horizontal: n × 360° continuous rotation |
|
Pitch: -45° to +45° |
|
|
Rotation speed |
Horizontal: 0.006°-30°/s |
|
Pitch: 0.006°~30°/s |
|
|
Position accuracy |
≤0.02° (0.3mil) |
|
Repeatability |
≤0.06° (1 mil) |
|
Screen size |
1200*1080 2.95 inches |
|
Memory capacity |
128GB (optional up to 2TB) |
|
Map Format |
Satellite map /contour map (supports user-programmed software) |
|
coordinate system |
WGS84/CGCS2000/SK42/Myanmar Datun 2000, etc. (customizable) |
|
Gauss-Kruger/UTM/MGRS, etc. (customizable) |
|
|
North |
Magnetic North /True North/Coordinate North |
|
database |
Supports CSV file import/export |
|
Video stream input |
CVBS/HDMI |
|
working power supply |
DC 12-36V |
|
Image transmission and data transmission |
RTSP |
|
physical parameters |
|
|
size |
180mm*135mm*220mm |
|
weight |
≤4Kg |
|
Components |
|
|
Data cable |
16-pin multi-functional data cable |
|
19-pin HDMI cable |
|
|
6-pin external DC power cable |
|
|
12-pin Ethernet cable |
|
|
5-pin USB adapter cable |
|
|
tool |
1/4 Quick-release adapter |
|
Cleaning tools |
|
|
Assembly tools |
|
|
tripod |
Lightweight quick-release tripod |
|
Packing box |
Integrated safety transport box |
|
Written documents |
User Manual |
|
Quick Start Guide |
|
|
Warranty card |
|
Application：Temporary battlefield deployment, surprise reconnaissance, artillery reconnaissance, etc.
